Patol ADB 500 Automatic Blowout Device for One Sampling Pipe (50-0500571-01-01P)

Patol ADB 500 Automatic Blowout Device for One Sampling Pipe (50-0500571-01-01P)

The automatic blow out device ADB 500 is used as an accessory part for an Aspirating Smoke Detector in areas with high levels of dust and dirt.

With the blow out device, the aspirating smoke detector's sampling pipe is automatically blown through and cleaned to prevent fault messages due to contaminated suction openings and false alarms. This way, the lifespan of the smoke sensor in the aspirating smoke sensor is increased considerably.

When using the automatic blow out device, a combination with the accessory components dust filter unit DFU 911 and dust retaining box DRB 25 is generally recommended. Optionally, the filter-box FBX 25 (extra-large) and the dirt trap box DTB 25 can be used.

Key Features

• Prevention of fault messages caused by contaminated suction openings.
• Lengthening of lifespan of smoke detectors / smoke sensors
• Prevention or substantial reduction of false alarms
• Fault message in the case of compressed air failure (detection period can be freely programmed)
• Applicable for all aspirating smoke detectors
• Subsequent installation possible at any time
• Low installation costs
• Maintenance friendly
