Ziton DC-9103E Conventional Optical Detector (Rate of Rise)

Ziton DC-9103E Conventional Optical Detector (Rate of Rise)

The DC-9103E is a configurable conventional rate-of- rise or fixed temperature heat detector.

Application

The detector supports installation on the GST DB-01 conventional detector base for standard applications, or the GST DB-01D diode base when head-out functionality to BS5839 standard is required. Detection configuration is programmable using the GST P-9910B device programmer.

Key Features:

• Self-diagnostic
• Local test activation with reed switch
• All round LED visibility (360° viewing angle) avoids time spent on specific detector orientation
• Configurable polling LED support
• Remote indicator output
• 3 Programmable operating levels (A1R, A2S and BS)
