Ziton FF766 Triple IR Flame Detector In Eexd Flameproof Housing

Ziton FF766 Triple IR Flame Detector In Eexd Flameproof Housing
Brand: Ziton

Owing to present delivery delays from the OEM of this product, please see alternative equipment below for your consideration with regard to your on-going Projects:

Spectrex SharpEye 40/40I Triple IR (IR3) Flame Detector

Triple IR Flame Detector - FlameSpec-IR3

Ziton FF766 Triple IR Flame Detector In Eexd Flameproof Housing

IR3 (Infra red) Flame detector in a flame proof housing provides excellent response to flaming fires with superb immunity to extraneous sources, suitable for hazardous areas certified EExd IIC T6.

The FF766 is a IR³ flame detector in a flame proof housing. IR³ models have execellent response to flame while providing superb immunity to extraneous sources. New micro-processor technology makes the detectors independent of flame intensity enabling it to operate through smoke, a layer of oil, dust, or water vapor. A high and low sensitivity setting according to EN54-10 is provided.

The units can be wired as conventional 2 wire, 4-20 mA, or relay contacts(fire, fault and pre alarm) in latching or non-latching operation. Remote test inputs are available to activate self-test. A stainless steel adjustable bracket and weather shield is also available. The units are tolerant to vibration, and wind does not affect the performance. The IR³ unit has excellent tolerance to detector window contamination and can detect flame through glass windows. A flame sensor test unit is available for accurate testing of the detectors.

Most IR flame sensors respond to 4.3 m light, emitted by hydrocarbon flames. By responding to 0.75 to 2.7 m light emitted by every fire, all flickering flames can be detected. Gas fires not visible to the naked eye e.g. hydrogen may also be detected. The IR³ detectors, responding to adjacent IR wavelengths, enable it to discriminate between flames and spurious sources of IR radiation. The combination of filters and signal processing allows the sensor to be used without risk of false alarms in difficult situations characterised by factors such as flickering sunlight.


  • Triple IR detector
  • High specification units for critical applications
  • IP66 Housing
  • Flame proof housing
  • Low current consumption
  • 2 Wire, 4 - 20 mA and relay operation
  • Latching and non latching operation
  • High / Low sensitivity setting
  • Tolerance to detector window contamination
  • Remote self test facility
  • Microprocessor controlled
  • Immunity to false sources (arc welding, lightning and static)
  • EN54-10 & CPD approved
