Ziton ZC6-MCP-IS Intrinsically Safe Surface Mount Call Point 172120

Please note: This product is now obsolete, the recommended replacement is the Ziton DMN700E-IS Intrinsically Safe Manual Outdoor Call Point.

Ziton ZC6-MCP-IS Intrinsically Safe Surface Mount Call Point 172120

The ZC6-MPC-IS intrinsically safe callpoint, provides a manual means of raising an alarm in areas made hazardous by the presence of explosive gasses. Complying with EN54 Part 11, the unit carries full SIRA certification to ATEX Directive 94/9/EC.

Analogue or Conventional

The call point can be used in addressable systems by interfacing the intrinsically safe spur to the loop wiring via an addressable interface and galvanic isolator, or in conventional installations wired as a zone, again via a suitable barrier.

The MCP is operated either by pressing a re-settable element (EN54 Part 11) or by breaking a frangible glass with finger pressure. Glass elements have clear vinyl coatings on the front surface to prevent operator injury and to inhibit the release of loose fragments as the glass is broken. Both operating elements are easily interchangeable.

Push in terminals

ZC6-MCP-IS callpoints are designed for semi recessed fixing, using a standard single gang socket box, or can be surface mounted by means of a matching plastic back box. Push in terminals enable the device to be plugged directly into the detector IS zone wiring, ,making replacement simple and reducing internal cable ends to a minimum. System testing, glass replacement and reset are carried out by using a special maintenance tool enabling part of the front moulding, including the glass, to be lowered allowing the device to operate.

Optional front cover

For locations where malicious operation, or accidental impact from flying objects mat occur, operation can be restricted by the addition of a clear, polycarbonate, front cover that can be further protected by a cover seal. In use the seal must be broken, prior to raising the front cover.

Key Features

• SIRA certificated
• Modern stylish design
• Resettable or frangible operating elements
• Plug in wiring connection
• Single maintenance tool
