C-Tec CA732 CA Zone Monitor Module

C-Tec CA732 CA Zone Monitor Module

The C-Tec CA732 is a CA Zone monitor module using the C-Tec CAST analogue addressable protocol.

‘CAST’ is the world’s most-advanced ‘distributed intelligence’ fire alarm system protocol. Conceived, designed and realised by C-TEC as part of a five-year, multi-million pound project, it involved the creation of a powerful proprietary communication protocol (C-TEC Addressable System Technology, CAST) and multiple control panels & field devices.

Key Features

• LPCB certified to EN54-17 & 18 and Kiwa Telefication certified to EN54-13
• A single-zone addressable Zone Monitor capable of supporting up to 20 conventional fire detectors and 10 MCPs
• Mountable on a standard UK 25mm double gang back box
• Onboard short-circuit loop isolator
• 4mA typical alarm current (1.1mA typical quiescent current) @ 22-40V DC
• Indicators for Loop polling, input faults and relay status
• Alternatively, can be used as general purpose input monitor
• Mountable on a C-TEC NCP-26 surface box or a standard UK 25mm double gang back box (not supplied)
