Duo-Cel 2 Zone Control Panel – 2605548

***PLEASE NOTE*** - Under the regulations only products approved to current EN standards may be CE marked for use in installation within the EU, countries other than EU are not affected.

We advise that the following products will not carry the CE marking and therefore should not be used on new installation within EU from July 1^st 2013

Duo-Cel 2 Zone Control Panel – 2605548

Duo-Cel panels are 2 Wire and come in a range from 2 zones, 4 zones and 8 zones. Based on the technology of our top range panels the Duo-Cel has been developed to bring our budget panel range up to date regarding functionality, and necessary approvals. The panel supports a wide variety of commonly available detectors, call points and sounders from various manufacturers and has many useful configurable options, inputs and outputs to aid with installation and retrofitting.

Key Features:

• EN54 with CPD Approval
• 2, 4 & 8 Zone versions available in an aesthetically pleasing design.
• Sturdy, flame retardant, ABS plastic enclosure with controls, zone text insert & indications overlay
• Easy to install, program and use. Key operated controls access (no ‘user confuser’ codes!)
• Panel can be surface or semi flush mounted & has 20mm cable gland breakouts
• Comprehensive LED indications and user/engineer controls
• Low standby power consumption.
• 4 Sounder circuits 4 & 8 zone, 2 on 2 zone panel. Zonal & Alert sounder options configurable
• 1.5A switched mode power supply with temperature compensated battery charging
• Enclosure houses 3.4Ah SLA batteries as standard
• 8 Zone repeaters available with 24V or mains operation
• Width 365mm x Height 273mm x Dimension 110mm
